(2005–2009 Mustang)
S197 Mustang — Early Platform
Wheels from this range are built around the 2005–2009 steering wheel platform and are not interchangeable with 2010–2014. If your Mustang is a 2005, 2007, or 2009 model, use this range to keep fitment and OEM functions consistent.
(2010–2014 Mustang)
S197 Mustang — Next Gen
This section covers S197 2010–2014 fitment, which uses a different steering wheel platform than 2005–2009. If your Mustang is 2010–2014 (including many 2014 Mustang GT builds), choose this range to match the correct mounting/fitment and retain OEM functionality.
(2015–2023 Mustang)
S550 Steering wheels
Built for 2015–2023 Mustangs - including GT, EcoBoost, Bullit, Mach 1 and others —built to integrate cleanly with factory controls and airbag while upgrading the interior with real carbon fiber and premium grip materials.
Fits 2024+ Mustang (S650)
S650 Mustang Steering wheels
For the newest Mustang generation. Designed for the S650 interior so fitment stays clean and OEM-style.
Carbon Quality Comparison
In this video we compared our Mustang carbon fiber center console with another manufacturer of carbon console side by side to show how finish quality can vary. In the highlighted areas, you can see differences in weave consistency, surface clarity, and overall fit-and-finish - details that matter when you want an interior upgrade to look clean, OEM-level and premium look. We recommend you to run video in 4k to see the difference in details.
Manufacturing Proof (Real Carbon Fiber Construction)
Some “carbon fiber” steering wheels on the market use overlays, hydro-dip patterns, or cosmetic wraps. This video shows how our carbon parts are made and finished, so you can see that its true carbon.
Customization Options
Choosing the right steering wheel is mostly about matching your interior style and driving feel. Below are the main customization options available across our Mustang steering wheel builds.
Carbon Type
Twill carbon has a clean, uniform weave pattern and a more classic carbon look. Forged carbon has a marbled, irregular texture that stands out in modern builds. We also offer 4x4 twill carbon for some generations.
Carbon Color
Choose a carbon color that matches your build theme. Our standard option is grey, with additional color options available in blue, red, purple and green depending on configuration.
Finish
Gloss highlights the carbon pattern with a deeper, reflective look. Matte keeps a more understated appearance and reduces reflections in bright daylight.
Grip Material
Leather is durable and easy to maintain. Alcantara-style provides a softer, higher-grip feel (where available), often preferred for a more performance-oriented interior.
Accent Details
Accent options help match the wheel to your interior theme. Stripe and stitching colors can be chosen to complement seats, belts, or existing interior details.
OEM Fitment & Installation Overview
Most Mustang owners ask two things before upgrading their steering wheel: will it fit correctly, and will the factory airbag and controls still work? Our wheels are built around OEM compatibility. Check our video which is a step-by-step overview of the installation process.
Installation Steps
Installation time: Approximately 20–40 minutes
Difficulty level: Medium. (We also offer in-house installation by our expert team)
1. Steering Wheel Overview
Quick walkthrough of the wheel (carbon top, stripe, Alcantara/leather, and the color-matched edge accent trim).
2. Required Tools
Before beginning installation, prepare the necessary tools. Typical tools include:
- 4mm Allen key (airbag release)
- 24mm socket (center bolt)
- 10mm socket
- Torx driver (used for wheel screws)
- Plastic trim removal tools
3. Airbag Removal
Disconnect the battery before working with the airbag system.
- Use the Allen key through the two side holes to push the spring pins and release the airbag (one side, then the other).
- Disconnect the airbag connectors (yellow connectors; lift the orange lock if needed).
- Remove the center bolt with the 24mm socket while holding the wheel.
- Disconnect the gray connector (controls harness) and keep the wheel aligned as you pull it off.
4. Steering Wheel Assembly & Installation
Transfer necessary components from the factory steering wheel as required for your model. Align the new carbon fiber steering wheel correctly on the column, secure the mounting bolt to proper torque specifications, reconnect wiring, and reinstall the airbag.
After installation, reconnect the battery and verify that all controls function properly and no warning lights are present.
S650 Builds
Warranty, Lead Time & Shipping
2 Years Warranty
Because we stand behind our quality.
Lead time
Lead time depends on configuration and current production queue. Manufacturing time for parts that are not in stock is 6-8 weeks.
Shipping
We ship worldwide using your preferred shipping carrier or service whenever available. Tracking is provided once your order is dispatched.
FAQs
Does this fit my Mustang year?
Fitment depends on generation and year. Use the S197/S550/S650 tabs above and confirm your exact model before ordering. Or simply follow our step-by-step quiz (car icon in the header) to see compatibility details
Will my airbag and factory controls still work?
These wheels are built around OEM-style compatibility so your original airbag and controls can integrate as intended for your generation.
Is you carbon fiber parts replacement or overlays?
All our carbon fiber parts are 100% replacement.
Can I make a custom order?
Yes we accept a custom orders that are previously discussed and agreed upon during a phone call.
